SUPERARTIC 250 ECT-F PLUS

Code SUA0253

Low temperature laboratory freezer (temperature range: -20°C / -40°C), solid door type, medium size, stainless steel internal structure, with increased insulation, developed for laboratories, hospitals and pharma industries

-20 / -40°C Temperature range

280 lt (9.89 cu ft) Capacity

67 x 81 x 159 cm External dimensions (WxDxH)

ECT-F PLUS Electronic Controller

Request a quote

Laboratory freezer 'till -40°C, solid door type and dislay with alarms, even in the event of a power failure.

Laboratory freezers series SUPERARTIC feature a clean and functional design, heavy duty and easy to use type, with solid door and adjustable compartments to enhance product storage.

They have been specifically designed for the use in laboratories and industry (not only pharma): SUPERARTIC freezers comply with international standards in force and answer the professional needs of research centers requiring stabilized temperatures down to -40°C and high performances.

The solid door and the oversize insulation thickness guarantee the most efficient performance, while the intelligent defrosting and automatic evaporation of condensation water avoid machine downtime and ice formation. Fiocchetti’s aesthetic design is also apparent in the door, thanks to its ergonomics, with recessed handle and reversible opening direction.

FEATURES
CONTROLLER
TECHNICAL DATA

Download Resources

STRUCTURE AND REFRIGERATION

Inner dimensions: 51 x 61 x 91,5 cm

Nominal capacity: 250 l (8,82 cu ft)

Net capacity : 250 lt (8,84 cu ft)

Insulation type: Insulation in PUF injected at very high density (43 kg/m3), without any CFC and with water-foam based injection.

Insulation thickness: 80 mm

Structure: Monocoque type, made of 18/10 Aisi 304 stainless steel interior, and exterior in plasticized, atoxic white steel exterior, coated with a special antibacterial-type film. Inner bottom rounded corners. Nr 4 unidirectional rollers included to grant an easy handling and nr 2 front feet for a maximum stability

Refrigeration type: Professional ventilated

Defrost type: Automatic, adaptive, with vaporization of condensate water

ECT-F PLUS MICROPROCESSOR CONTROLLER

Temperature display and setting with: Display resolution: 0,1°C accuracy ± 0.3°C with backlit 16-character alphanumeric LCD display customizable in 5 languages, keyboard with 4 membrane keys able to communicate with the user by providing immediate and precise information on the status of the equipment.

It also has a back-up battery for power failure alarm for up to 48 hours, a minimum/maximum temperature recording and potential free contact for remote alarms. Configurable and customizable display in four different reading modes
Keyboard: 4 simple membrane keys allow you to operate by following the intuitive instructions provided by the display. The user has the possibility to customize the password to protect switching on, switching off and changing the set-point and checking alarms even in the event of a power failure.

Alarms: The controller signals different types of temperature alarms, including high temperature alarm due to power failure, and records 12 events, in addition to the minimum and maximum temperature, which can be reset by the user . The dry contact on the board allows to remotely control the alerts.

REFRIGERATOR TECHNICAL DATA

Refrigerant gas type: R290
Energy consumption: 6 kWh/24h
Power absorption/current: kW 2 / Amp 8,3
Inrush current: 3 Amp
Noise level: <55 dBA
Heat rejection EN 12900: W 250
Shelves max nr.: 4
Wire shelves dimensions: cm 47x60
Drawers max nr.: 4
Inner dimensions of drawers with dividers (LxPxH) (each compartment): cm 12x55x7,5 (3)
Inner dimensios of drawers without dividers (LxPxH): cm 39x55x7,5
